#include <Wire.h>
//#include <Adafruit_GFX.h>
#include <Adafruit_SSD1306.h>
#include <U8g2_for_Adafruit_GFX.h>
#include <WiFiMulti.h>
#include "WiFi.h"
#include "Audio.h"
#include "Rotary.h"
#include "ScrollText.h"
enum STATE { NORMAL, MENU, VOLUME, FUNCTION };
STATE state = NORMAL;
// Enconder PINs
#define ENCODER_PIN_A 1
#define ENCODER_PIN_B 2
#define PUSH_SW 21
// Declaration for an SSD1306 display connected to I2C (SDA, SCL pins)
// The pins for I2C are defined by the Wire-library.
const uint8_t I2C_SDA = 18; //
const uint8_t I2C_SCL = 17; //
#define SCREEN_WIDTH (128)
#define SCREEN_HEIGHT (64)
//#define SCREEN_HEIGHT (32)
#define VUPOS_X (96)
#define VUPOS_Y (1)
#define VOLPOS_X (8)
#define VOLPOS_Y (22)
// 8×8 のビットマップ（例：笑顔アイコン）
const uint8_t smiley[8] PROGMEM = {
0b00111100,
0b01000010,
0b10100101,
0b10000001,
0b10100101,
0b10011001,
0b01000010,
0b00111100
};
// 8×8 のビットマップ（例：アンテナアイコン）
const uint8_t antena[8] PROGMEM = {
0b11111110,
0b01010100,
0b00111000,
0b00010000,
0b00010000,
0b00010000,
0b00010000,
0b00000000
};
// 8×8 のビットマップ（例：アンテナアイコン）
const uint8_t antenaNG[8] PROGMEM = {
0b11111110,
0b11010110,
0b00111000,
0b01010000,
0b00111000,
0b01010100,
0b10010010,
0b00000000
};
const uint8_t antena0[8] PROGMEM = {
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b00000000
};
const uint8_t antena1[8] PROGMEM = {
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b01000000,
0b00000000
};
const uint8_t antena2[8] PROGMEM = {
0b00000000,
0b00000000,
0b00000000,
0b00000000,
0b00010000,
0b00010000,
0b01010000,
0b00000000
};
const uint8_t antena3[8] PROGMEM = {
0b00000000,
0b00000000,
0b00000100,
0b00000100,
0b00010100,
0b00010100,
0b01010100,
0b00000000
};
const uint8_t antena4[8] PROGMEM = {
0b00000001,
0b00000001,
0b00000101,
0b00000101,
0b00010101,
0b00010101,
0b01010101,
0b00000000
};
// 8×8 のビットマップ（例：アンテナアイコン）
const uint8_t wifi_ant[8] PROGMEM = {
0b01111100,
0b10000010,
0b00111000,
0b01000100,
0b00010000,
0b00101000,
0b00010000,
0b00000000
};
#define OLED_RESET (-1)
#define SCREEN_ADDRESS (0x3C)
Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET);
U8G2_FOR_ADAFRUIT_GFX u8g2_for_adafruit_gfx;
//for scroll text
ScrollingText scroller1(u8g2_for_adafruit_gfx, SCREEN_WIDTH, 32, u8g2_font_unifont_t_japanese1, -2);
ScrollingText scroller2(u8g2_for_adafruit_gfx, SCREEN_WIDTH, 48, u8g2_font_unifont_t_japanese1, -3);
// Digital I/O used
# define I2S_DOUT 11 // DIN connection
# define I2S_BCLK 13 // Bit clock
# define I2S_LRC 12 // Left Right Clock
Audio audio;
String stations[] ={
"radio-stream.nhk.jp/hls/live/2023229/nhkradiruakr1/master.m3u8", //NHK 1
"radio-stream.nhk.jp/hls/live/2023501/nhkradiruakr2/master.m3u8", //NHK 2
"radio-stream.nhk.jp/hls/live/2023507/nhkradiruakfm/master.m3u8", //NHK FM
"stream.laut.fm/animefm",
"cast1.torontocast.com:2120/;.mp3",
"cast1.torontocast.com:2170/;.mp3",
// "cast1.torontocast.com/JapanHits",
// "cast1.torontocast.com:2120/stream",
"s3.radio.co/sc8d895604/listen",
"kathy.torontocast.com:3060/;?shoutcast",
"vrx.piro.moe:8000/stream-256",
"vocaloid.radioca.st/stream", //Vocaloid Radio
"mtist.as.smartstream.ne.jp/30043/livestream/chunklist.m3u8", //MWave
"mtist.as.smartstream.ne.jp/30081/livestream/chunklist.m3u8", //
"ice1.somafm.com/illstreet-128-mp3", // SomaFM / Illinois Street Lounge
"ais-sa2.cdnstream1.com/b22139_128mp3", // 101 SMOOTH JAZZ
"relax.stream.publicradio.org/relax.mp3", // Your Classical - Relax
"ice1.somafm.com/secretagent-128-mp3", // SomaFM / Secret Agent
"ice1.somafm.com/seventies-128-mp3", // SomaFM / Left Coast 70s
"ice1.somafm.com/bootliquor-128-mp3", // SomaFM / Boot Liquor
"shonanbeachfm.out.airtime.pro:8000/shonanbeachfm_a", // FM Blue Shonan (FM・ブルー湘南 , JOZZ3AD-FM, 78.5 MHz, Y...
"0n-80s.radionetz.de:8000/0n-70s.mp3",
"mediaserv30.live-streams.nl:8000/stream",
"mp3.ffh.de/radioffh/hqlivestream.aac", // 128k aac
"listen.rusongs.ru/ru-mp3-128",
};
uint8_t cur_station = 0; // current station No.
uint8_t num_elements = sizeof(stations) / sizeof(stations[0]);
volatile int encoderCount = 0;
// Encoder control
Rotary encoder = Rotary(ENCODER_PIN_A, ENCODER_PIN_B);
//Wifi
WiFiMulti wifiMulti;
/*
Reads encoder via interrupt
Use Rotary.h and Rotary.cpp implementation to process encoder via interrupt
*/
void rotaryEncoder()
{ // rotary encoder events
uint8_t encoderStatus = encoder.process();
if (encoderStatus)
encoderCount = (encoderStatus == DIR_CW) ? 1 : -1;
}
// callbacks
#if 0
void my_audio_info(Audio::msg_t m) {
Serial.printf("%s: %s\n", m.s, m.msg);
}
#else
// detailed cb output
void my_audio_info(Audio::msg_t m) {
switch(m.e){
case Audio::evt_info: Serial.printf("info: ....... %s\n", m.msg); break;
case Audio::evt_eof: Serial.printf("end of file: %s\n", m.msg); break;
case Audio::evt_bitrate: Serial.printf("bitrate: .... %s\n", m.msg); break; // icy-bitrate or bitrate from metadata
case Audio::evt_icyurl: Serial.printf("icy URL: .... %s\n", m.msg); break;
case Audio::evt_id3data: Serial.printf("ID3 data: ... %s\n", m.msg); break; // id3-data or metadata
case Audio::evt_lasthost: Serial.printf("last URL: ... %s\n", m.msg); break;
case Audio::evt_name: Serial.printf("station name: %s\n", m.msg);
scroller1.setText(m.msg);
break; // station name or icy-name
case Audio::evt_streamtitle: Serial.printf("stream title: %s\n", m.msg);
scroller2.setText(m.msg);
break;
case Audio::evt_icylogo: Serial.printf("icy logo: ... %s\n", m.msg); break;
case Audio::evt_icydescription: Serial.printf("icy descr: .. %s\n", m.msg); break;
case Audio::evt_image: for(int i = 0; i < m.vec.size(); i += 2){
Serial.printf("cover image: segment %02i, pos %07lu, len %05lu\n", i / 2, m.vec[i], m.vec[i + 1]);} break; // APIC
case Audio::evt_lyrics: Serial.printf("sync lyrics: %s\n", m.msg); break;
case Audio::evt_log : Serial.printf("audio_logs: %s\n", m.msg); break;
default: Serial.printf("message:..... %s\n", m.msg); break;
}
}
#endif
void setup() {
Audio::audio_info_callback = my_audio_info; // optional
rgbLedWrite(RGB_BUILTIN, RGB_BRIGHTNESS, 0, 0); // Red
pinMode(ENCODER_PIN_A, INPUT_PULLUP);
pinMode(ENCODER_PIN_B, INPUT_PULLUP);
pinMode(PUSH_SW, INPUT_PULLUP);
Serial.begin(115200);
// while (!Serial); // シリアルモニタが開くまで待つ
delay(10);
//setup I2C
Wire.begin(I2C_SDA, I2C_SCL);
//setup SSD1306
if(!display.begin(SSD1306_SWITCHCAPVCC, SCREEN_ADDRESS)) {
for(;;);
}
u8g2_for_adafruit_gfx.begin(display); // connect u8g2 procedures to Adafruit GFX
display.clearDisplay();
u8g2_for_adafruit_gfx.setFontDirection(0); // left to right (this is default)
u8g2_for_adafruit_gfx.setForegroundColor(WHITE); // apply Adafruit GFX color
u8g2_for_adafruit_gfx.setFont(u8g2_font_7x13_te); // icon font
u8g2_for_adafruit_gfx.setFontMode(1); // use u8g2 transparent mode (this is default)
u8g2_for_adafruit_gfx.setCursor(32,16); // start writing at this position
u8g2_for_adafruit_gfx.println(F(" ESP32-S3"));
// u8g2_for_adafruit_gfx.setFont(u8g2_font_siji_t_6x10); // icon font
// u8g2_for_adafruit_gfx.setFontMode(1); // use u8g2 transparent mode (this is default)
u8g2_for_adafruit_gfx.setCursor(0,32); // start writing at this position
u8g2_for_adafruit_gfx.println(F(" WebRadio V3.0"));
u8g2_for_adafruit_gfx.print(F(" 2025/8/29"));
display.display();
Serial.println("SSD1306 OK");
#if 0
WiFi.disconnect();
WiFi.mode(WIFI_STA);
WiFi.begin(ssid.c_str(), password.c_str());
while (WiFi.status() != WL_CONNECTED) delay(1500);
Serial.println("WiFi start");
#else
WiFi.disconnect();
WiFi.mode(WIFI_STA);
/*Type all known SSID and their passwords*/
wifiMulti.addAP("xxxxxxxx", "xxxxxxx"); /*Network 1 we want to connect*/
wifiMulti.addAP("xxxxxxxx", "xxxxxxx"); /*Network 2 we want to connect*/
// WiFi.scanNetworks will give total networks
int n = WiFi.scanNetworks(); /*Scan for available network*/
Serial.println("scan done");
if (n == 0) {
Serial.println("No Available Networks"); /*Prints if no network found*/
}
else {
Serial.print(n);
Serial.println(" Networks found"); /*Prints if network found*/
for (int i = 0; i < n; ++i) {
Serial.print(i + 1); /*Print the SSID and RSSI of available network*/
Serial.print(": ");
Serial.print(WiFi.SSID(i));
Serial.print(" (");
Serial.print(WiFi.RSSI(i));
Serial.print(")");
Serial.println((WiFi.encryptionType(i) == WIFI_AUTH_OPEN)?" ":"*");
delay(10);
}
}
/*Connects to strongest available defined network with SSID and Password available*/
Serial.println("Connecting to Wifi...");
#if 0
if(wifiMulti.run() == WL_CONNECTED) {
Serial.println("");
Serial.print("Connected to WIFI Network: ");
Serial.println(WiFi.SSID());
Serial.print("IP address of Connected Network: ");
Serial.println(WiFi.localIP()); /*Prints IP address of connected network*/
rgbLedWrite(RGB_BUILTIN, 0, RGB_BRIGHTNESS, 0); // Green
}
#else
while (WiFi.status() != WL_CONNECTED) {
wifiMulti.run();
// delay(1000);
if (WiFi.status() == WL_CONNECTED) {
Serial.println("");
Serial.print("Connected to WIFI Network: ");
Serial.println(WiFi.SSID());
Serial.print("IP address of Connected Network: ");
Serial.println(WiFi.localIP()); /*Prints IP address of connected network*/
rgbLedWrite(RGB_BUILTIN, 0, RGB_BRIGHTNESS, 0); // Green
}
else {
Serial.println("Wi-Fi Nothing!\nRetry!!");
}
}
#endif
#endif
//Audio
audio.setPinout(I2S_BCLK, I2S_LRC, I2S_DOUT);
audio.setVolume(12); // 0...21
rgbLedWrite(RGB_BUILTIN, 0, 0, RGB_BRIGHTNESS); // Blue
Serial.println("audio start");
//set first station
audio.connecttohost(stations[cur_station].c_str());
Serial.println(stations[cur_station].c_str());
//display station
scroller1.setText(F(stations[cur_station].c_str()));
/* ---------- スクロール設定 ---------- */
display.setTextSize(2);
display.setTextColor(WHITE);
display.setTextWrap(false);
// Encoder interrupt
attachInterrupt(digitalPinToInterrupt(ENCODER_PIN_A), rotaryEncoder, CHANGE);
attachInterrupt(digitalPinToInterrupt(ENCODER_PIN_B), rotaryEncoder, CHANGE);
}
void loop() {
static unsigned long lastUpdate = 0;
const uint32_t UPDATE_MS = 10000; //
if (millis() - lastUpdate < UPDATE_MS) {
;
}
else {
lastUpdate = millis();
state = NORMAL;
// Serial.println(lastUpdate);
}
//audio
audio.loop();
//display wifi rssi
if (WiFi.status() != WL_CONNECTED) {
Serial.println("WiFi not connected!");
display.drawBitmap(0, 0, antenaNG, 8, 8, SSD1306_WHITE);
}
display.clearDisplay();
#if 1
display.drawBitmap(0, 0, antena, 8, 8, SSD1306_WHITE);
int rssi = WiFi.RSSI();
if (rssi > -55) {
display.drawBitmap(8, 0, antena4, 8, 8, SSD1306_WHITE);
}
else if (rssi > -67){
display.drawBitmap(8, 0, antena3, 8, 8, SSD1306_WHITE);
}
else if (rssi > -70){
display.drawBitmap(8, 0, antena2, 8, 8, SSD1306_WHITE);
}
else if (rssi > -80){
display.drawBitmap(8, 0, antena1, 8, 8, SSD1306_WHITE);
}
else {
display.drawBitmap(8, 0, antena0, 8, 8, SSD1306_WHITE);
}
#else
display.drawBitmap(0, 0, wifi_ant, 8, 8, SSD1306_WHITE);
display.setTextSize(1);
display.setCursor(8, 0);
display.print(WiFi.RSSI());
display.print("dBm ");
#endif
//display volume
display.setTextSize(1);
display.setCursor(80, 0);
display.print(audio.getVolume());
//displsy audio level
// Convert to bar width (0..32)
uint8_t barWidth = constrain((uint16_t)(audio.getVUlevel()/1024), 0, SCREEN_WIDTH / 4);
uint8_t barHeight = SCREEN_HEIGHT / 8 - 2; //level meter hight
display.fillRect(VUPOS_X, VUPOS_Y, barWidth, barHeight, WHITE);
// Optional: draw border
display.drawRect(VUPOS_X-1, VUPOS_Y-1, 32+1, barHeight+2, WHITE);
switch (state) {
case NORMAL:
// Check if the encoder has moved.
if (encoderCount != 0)
{
if (encoderCount == 1)
{
rgbLedWrite(RGB_BUILTIN, 0, RGB_BRIGHTNESS, 0); // Green
Serial.println("Encoder up");
cur_station = (cur_station == num_elements - 1) ? 0 : (++cur_station);
}
else
{
rgbLedWrite(RGB_BUILTIN, 0, RGB_BRIGHTNESS, 0); // Green
Serial.println("Encoder down");
cur_station = (cur_station == 0) ? (num_elements - 1) : (--cur_station);
}
encoderCount = 0;
audio.connecttohost(stations[cur_station].c_str());
Serial.println(stations[cur_station].c_str());
scroller1.setText(F(stations[cur_station].c_str()));
scroller2.setText("");
rgbLedWrite(RGB_BUILTIN, 0, 0, RGB_BRIGHTNESS); // Blue
}
else if (digitalRead(PUSH_SW) == LOW) {
Serial.println("Push");
vTaskDelay(500);
state = VOLUME;
lastUpdate = millis();
}
//display codec & bitrate
display.setTextSize(1);
display.setCursor(0, 8);
display.print("CH:");
display.print(cur_station);
display.print(" ");
display.print(audio.getCodecname());
display.print(":");
display.print(audio.getBitRate(false));
display.print("bps");
scroller1.update(); // 1フレーム分を描画
scroller2.update(); // 1フレーム分を描画
//display station url
display.display();
break;
case VOLUME:
// Serial.println("volume");
int vol = audio.getVolume();
//display volume control
display.setTextSize(1);
display.setCursor(32, 8);
display.print("Volume");
display.fillRect(VOLPOS_X, VOLPOS_Y, vol * 4, 8, WHITE);
// Optional: draw border
display.drawRect(VOLPOS_X-1, VOLPOS_Y-1, 21 * 4 + 1, 8 + 2, WHITE);
// Check if the encoder has moved.
if (encoderCount != 0)
{
if (encoderCount == 1)
{
Serial.println("Encoder up");
audio.setVolume((vol < 21) ? ++vol : 21); // 0...21
}
else
{
Serial.println("Encoder down");
audio.setVolume((vol > 0) ? --vol : 0); // 0...21
}
lastUpdate = millis();
}
else if (digitalRead(PUSH_SW) == LOW) {
Serial.println("Push");
state = NORMAL;
vTaskDelay(500); //チャタリング対策
}
encoderCount = 0;
display.display();
break;
// default:
// break;
}
vTaskDelay(1);
}
最近のコメント
